• High Capacity (-E) versions

• Subminiature “sugar cube” relay with universal footprint.

• Conforms to EN 61810-1. UL recognized/ CSA certified.

• UL class-F coil insulation model available (UL class-B coil insulation for standard model).

• Withstands impulse of up to 4,500 V.

• 400-mW and 360-mW coil power types available.

• RoHS Compliant

    SCHRACK Power Relay RF

    Marque : TE CONNECTIVITY
    TE Internal #: 6-1415510-1
    TE Internal Description: RFH34012
    Power Relay Type : Standard
    Coil Magnetic System : Monostable, DC
    Coil Power Rating Class (mW): 300 – 400
    Coil Power Rating DC (mW): 400
    Coil Resistance (Ω): 360

Série OJ / OJE

Bobine d'isolement à contacter; Tension de

commutation 4000Vac ; Matériel de

contact 250Vac ;

Dimensions de l' alliage agricole; 14,6 x 18,2 x 10,2 mm

Relais à usage général SPST-NO (1 forme A) 24VAC bobine montage châssis
