Waveshare Open107V Standard, STM32F1 Development Board

STM32 development board designed for STM32F107V series, features the STM32F107VCT6 MCU, and integrates various standard interfaces, pretty easy for peripheral expansions.

Overview
Open107V is a STM32 development board that features a STM32F107VCT6 device as the microcontroller. It supports further expansion with various optional accessory boards for specific application. The modular and open design makes it the ideal for starting application development with STM32 connectivity line microcontroller.
Note: Open107V Standard includes only ONE accessory board -- PL2303 USB UART Board (mini).

What's On Board

STM32F107VCT6:the high performance STM32 MCU which features:

Core: ARM Cortex-M3 32-bit RISC
Operating Frequency: 72MHz, 1.25 DMIPS/MHz
Operating Voltage: 2-3.6V
Package: LQFP100
I/Os: 80
Memories: 256K Flash, 64K RAM
Communication Interfaces: 3 x SPI, 3 x USART, 2 x UART, 2 x I2S, 2 x I2C, 1 x Ethernet MAC, 1 x USB OTG, 2 x CAN
AD & DA converters: 2 x AD (12-bit, 1μs, shares 16 channels); 2 x DA (12-bit)
Debugging/Programming: supports JTAG/SWD (serial wire debug) interfaces, supports IAP


AMS1117-3.3: 3.3V voltage regulator
Power supply switch: 5V DC or USB
Power indicator;
LEDs: Convenient for indicating I/O status or program running state
Reset button;
User key;
Joystick: Convenient for I/O input (five positions)
32.768K crystal oscillator: for internal RTC
25M crystal oscillator;
Ethernet Interface: easily connects the MCU to ethernet network by using an additional ethernet module
8 I/O Interface: easily connects to keypad, motor, etc.
CAN1 Interface: communicates with accessory boards which feature the CAN device conveniently
CAN2 Interface: communicates with accessory boards which feature the CAN device conveniently
SPI1/SPI2 Interface: easily connects to SPI peripherals such as D
